Two color rotary table pad printing machine

FC-162BRC(old FC-202)-Two color rotary table pad printing machine



Fine Cause's pad printing machine imported to industrial I.O.T., combine smart factory App, assist you to implement production management goals through synchronous monitoring.

■ Features：

• 7.0" HMI touch panel with 65536 color TFT, built-in Chinese, English, Bahasa language, Vietnamese and Thai.

• Color touch panel with Panasonic PLC - programmable logical controller which can adjusted by client needing

• The pad printing machine uses L shape casting structure：strong and easy to operate

• Able to share the same size of ink cup：60*90Ø(mm)

• Each machine of printing location can be adjusted

• Able to set up any one of the machine printing times and printing parameters

• The highest of rubber can be installed achieve 90mm

• The pressure of ink cup is adjustable, microcomputer with automatic sensor, easy for repair and convenient

• Input / output whole area display

• Fine Cause produced pad printers own exclusive patent (No. M311585) and is different from others which only use magnet for suction function. Our new double-axis ink-scarping system makes it better and cleaner for scraping the ink.


Specifications

■ Suitable for

toys, stationery, watches, accessories, electronic products, switches, buttons, lighter surface and so on.

Plastic printing, metal finished products, semi-finished products, glass ceramics product or uneven surface printing.

Additional precision indexing plate makes it easy to access materials.It is also able to expand the automation peripherals to increase production.
