Oven/Vertical Oven
Handheld UV Machine
FC-XLITE400Q
- Features
- handheld UV machine can be equipped with either long wavelength UV lamp (TP) or long-short wavelength UV lamp (TQC), allowing for quick and easy replacement.
Description
The handheld UV machine can be conveniently moved to the curing position. Equipped with a heat dissipation box, which effectively reduces the temperature during standby to prolong the lifespan of lamp. The lampshade with handle is lightweight and there is a button switch on the handle; once the button is pressed, the timing starts and there will be a beep sound to remind when the set time is reached.
V ink will not dry without curing.
👉 Are you troubling with UV ink not drying properly despite using it for its good adhesion and abrasion resistance in printing?
★★★ This is a handheld UV machine that allows for the UV light to be freely moved to position above the object. Even large objects can be used. The weight of the lampshape is only about 1kg, making it convenient for operators to use.
👉 The handheld UV machine is equipped with a heat dissipation box, which effectively reduces the temperature during standby to prolong the lifespan of lamp.
👉 Widely used for curing UV ink and resin. It's ideal for industrial applications such us bonding, fixing, and sealing.
FC-XLITE400Q-Handheld UV Machine
- Long wavelength lamp or short wavelength lamp is optional.
- FC-XLITE400Q handheld UV machine can be equipped with either long wavelength UV lamp (TP) or long-short wavelength UV lamp (TQC), allowing for quick and easy replacement. It offers the flexibility to choose different lamp based on various ink and adhesive applications.
- The lampshade is movable, making it easy to cure various objects, large and small.
- FC-XLITE400Q handheld UV machine allows for the UV light to be freely moved to position above the object. Even large objects can be used. The weight of the lampshape is only about 1kg, making it convenient for operators to use.
- With digital timer setting, there will have reminding when the curing time is reached.
- FC-XLITE400Q handheld UV machine allows for setting the curing time, with the activation located on the handle.
- There will be a beep sound to remind when the set time is reached, which is convenient for setting a precise curing time.
Specifications
| FC-XLITE400Q Handheld UV Machine |
|
|---|---|
| Voltage | Single Phase 220VAC 50/60 HZ |
| UV Lamp Power | Lamp/400W |
| UV Intensity | 50-70 mW/cm2 |
| Main UV Wavelength | 254nm / 365nm |
| Average Lamp Life | 1000 hr |
| Timer Setting Range | 0.1sec-999.9min |
| Dimension (WxHxD) | Main Body:170x180x230mm Lampshade：150x110x160mm Handle Length：150mm Lampshade Stand：170x150x170mm |
| Weight | Total Weight：9.75kg (Handheld Part: 1.2kg) |
| Exhaust System | Air Cooling |
| Lamp Life Record | Digital Timer |
