Single-Color Pad Printing Machine
Automatic pad printer by single color
FC-161ANC-SB
- Features
- It belongs to a small automatic single-color ink cup pad printing machine
Description
This automatic pad printing machine has progressive propulsion fixture with cylinder operate. cylinder sliding base positioning fixture which will clamping object before printing automatic. auto discharge free-fall filler.
Single color pad printer (Auto discharge)-FC-161ANC-(old FC-125 SB)
Fine Cause's pad printing machine imported to industrial I.O.T., combine smart factory App, assist you to implement production management goals through synchronous monitoring.
■ Feature :
-
4.3 Inches Color Touch Panel
-
Malfunction screen display
-
Customize Pad positing base
-
Exclusive Patented "Adjustable Ink-Scraping Device" (Patent No. M311585). Adjust Scraping Pressure Easily.
-
Manual feeding structure
-
Progressive Propulsion fixture with cylinder operate
-
Cylinder Sliding Base Positioning fixture which will clamping object before printing automatic.
-
Auto discharge free-fall Filler
Specifications
| Model | FC-161ANC-SB |
|---|---|
| Color | 1 |
| Cycles/hr | 1200~1800 Pcs |
| Machine Size (cm) | L:63 W:60 H:120 |
| Weight | 110 Kgs |
| Pressure (kg/cm2 psi) |
4~6 |
| Power (A) Ampere |
5 |
| Voltage (V) | 110V |
| Max. Printing Area (mm) |
55 |
| Max. Height of Printed Object (mm) |
180mm |
| Height - Pad Stand to Steel Plate (mm) |
100 |
| Max. Steel Plate Size (mm) |
L:200 W:90 H:10 |
