Single Color Pad Printer
One-color horizontal pad printer
- Features
- Large pad printing machines can place materials for printing without waiting for the printing head to rise completely.
- Horizontal pad printing machines can be customized to increase the horizontal travel distance and expand the printing area.
Description
This (large) ink cup type pad printing machine is designed to increase the printing size by moving left and right. The maximum printing size under standard specifications is recommended to be 320*75mm, and the horizontal movement distance can be customized to increase printing range.
One-color horizontal pad printer-FC-391CNC
Fine Cause's pad printing machine imported to industrial I.O.T., combine smart factory App, assist you to implement production management goals through synchronous monitoring.
■ Feature :
-
Client can choose paid add additional installation peripheral devices like slide rail, round plate, oval plate, suction function, flip function, rotate function, and blow dryer shelf and so on
-
Built in smart bar chart, production data displayed by graphs in the past 30 days. Connect with FineCause smart factory APP, no matter where you are, you can overview the production data of your pad printer.
-
The pad printer is fully upgraded with a 10.1-inch color touch panel screen and PLC controller. Good visual effect, easy operation, easier and more convenient to use. The man-machine interface can be easily switched to select the language:English, Indonesian, Vietnamese ,Thai andTraditional Chinese.
-
Input & output full display
-
Abnormal warning display, convenient for quickly eliminate abnormalities
-
Digital pressure sensor, automatic alarm display for insufficient air pressure
-
Able to set the number of times which Pad-Print Printing is used, and it will automatically stop and display inform when the number is arrives.
-
-
PLC Programmable Logic Controller easy to add and modify function
-
Horizontal Ink Cup Scraping
-
The pad printing machine uses Patented Ink-Scraping Device. Adjustable Ink-Scraping Pressure
-
Embedded lighting equipment
-
Easy to add additional devices
-
Ex. slide rail, round plate, oval plate, suction function, flip function, rotate function, and blow dryer shelf, etc
-
■ Suitable For :
Products that need large size printing. For instance, Golf Ball (Need print around the ball).
Specifications
| Model / Specs | FC-391CNC | FC-361CNC |
|---|---|---|
| Ink cups size | 90 | 60 |
| Color | 1 | 1 |
| Pressure(kg/cm2 psi) | 4~6 | 4~6 |
| Power Consumtion(A) | 3 | 3 |
| Voltage (V) | 110-220V | 110-220V |
| Platform Size(mm) | 190*320 | 190*320 |
| Recommended printing size (mm) |
320*75 | 370*50 |
| Max. Height ofPrinted Object (mm) |
220 | 220 |
| Standard Stroke(mm) | 500 (Customized to extend the itinerary) |
500 (Customized to extend the itinerary) |
| Height -Pad Stand to Steel Plate(mm) |
300 | 300 |
| Steel Plate (mm) | 620*120 | 590*80 |
| Capacity/hr | 900~1200 | 900~1200 |
| Dimension (cm) | L:170 W:92 H:178 | L:170 W:92 H:178 |
| Net W. | 450KG | 450KG |
