Should I Choose a Pad Printer or a Screen Printer?

You can choose based on your production requirements and the characteristics of Pad Printing vs. Screen Printing.

Standard Screen Printing Machine (Silk Screen Printing)

FA-400/500/600TSN 400/500/600-Type Servo Motor Platform Screen Printer ↗

A Screen Printing Machine (also known as a Silk Screen Printing system) prints text and graphics on flat or regular surfaces. The printing area of a Screen Printer is relatively large. They can perform multi-color overprinting or connect multiple units into an automated production line.

Every Screen Printing Machine uses squeegee pressure to transfer ink through the mesh onto the substrate to form sharp patterns.

Screen printers and screen plates are designed and manufactured in Taiwan for high durability.

Features of FA-400/500/600TSN Electric Screen Printer:

This semi-automatic Screen Printing Machine is upgraded with a pneumatic pressure brake for screen lifting. When operating, air pressure is fully engaged with pneumatic braking, eliminating impact noise for smooth and quiet performance.

The upgraded screen mechanism utilizes digital height settings and pneumatic braking without hydraulic buffer cylinders, saving maintenance costs and eliminating manual height adjustments.

• Digital screen lift settings: Easily configure your desired screen elevation height via parameter settings at the lift stop position.
• Digital lift height controlled via Human-Machine Interface (HMI).
• Screen lifting uses pneumatic braking with digital control—quiet, rapid, and wear-free.
• Equipped with high-precision linear slide rails to provide stable support for the squeegee assembly, maintaining tight tolerances throughout the stroke.
• The rear base plate is made of aluminum alloy, offering lightweight agility and high precision for effortless vertical movement.
  • The extruded servo slider seat reduces weight for fast, stable, and silent operation.
• Left and right screen frame clamps move along linear guide rails, providing smoother and more accurate action than traditional T-slots.
• Built-in intelligent bar charts track production capacity and run times, storing data for the past 30 days.
  • Connects to the FINECAUSE Smart Factory App to monitor equipment output anytime, anywhere.
• Features a 7.0-inch TFT color touchscreen HMI with 5 built-in languages: Thai, English, Indonesian, Vietnamese, and Traditional Chinese.

• Input and output status indicators map the exact position of every sensor across the machine.
• Equipped with error alarm displays to assist operator troubleshooting quickly.
• Electronic air pressure sensing triggers automatic alerts when pressure falls below normal.
• Preset cycle limits for squeegees and screens automatically pause the machine and sound an alert when threshold counts are reached.
• Powered by a programmable logic controller (PLC) for easy functional customization:
  • Real-time display of servo motor operating positions on screen.
  • Stores multiple parameter recipes for quick setup.
• Adjustable squeegee pressure paired with precision pressure gauges.
• Magnetic/suction squeegee clip (Patent No. M390871)* allows quick positioning, adjustment, or removal.

...For detailed specifications, click here to view the FA-400/500/600TSN Servo Motor Platform Screen Printer...

Strictly packaged to deliver screen printing machinery safely to global clients.

Featured Standard Pad Printing Machine

FC-161ANC Smart Series Ink Cup Pad Printer (Ink Cup φ60) ↗

A standard Pad Printing Machine can print on virtually any irregular shape. Custom Pad Printer systems from FINECAUSE support up to 18 colors in a single setup.

The core mechanism of Pad Printing works by transferring etched patterns from a steel plate onto the substrate via a silicone pad.

FC-161ANC Pad Printer Features:

FINECAUSE single-color high-value Pad Printer equipped with rich functions and accessories 【Maximum Value】

Standard unit supplied with 60mm diameter ink cup (90mm diameter ink cup option available).

• Next-generation lightweight sliding sleeve with composite bearing seat—fast, stable, and precise.
• Built-in smart bar charts show production output, execution time, and 30-day historical data.
  • Connects to the FINECAUSE Smart Factory App to track machine capacity anywhere, anytime.
• 7.0-inch TFT color touchscreen display with 5 built-in languages: Thai, English, Indonesian, Vietnamese, and Traditional Chinese.

• Input and output indicators display sensor positions across the entire machine system.
• Fault alarm icons allow production line personnel to resolve issues swiftly.
• Electronic air pressure monitoring triggers automatic alerts if pressure drops below target.
• Set pad or plate usage count limits; the system stops automatically and issues an alert when reached.
• PLC programmable controller allows easy feature modifications or expansions:
  • Displays cylinder operating speeds directly on screen.
  • Stores multi-recipe parameters for quick switching.
• Safety feature prevents the silicone pad from dropping even if air pressure is lost during standby, protecting pads from damage.
• Pressure-adjustable squeegee mechanism (Patent No. M311585) for simple ink doctoring pressure adjustment.
• Computerized sheet metal construction with powder-coat finish and integrated body design (Patent No. M453283).

>..For detailed specifications, click here to view the FC-161ANC Ink Cup Pad Printer (φ60 Ink Cup)...

Our Pad Printer and Screen Printer models are exported to factories worldwide.

Precision instrument calibration and machine assembly.

Sample printing trials and OEM printing services.
