1-Color Pad Printing Machine
Custom pad printing machines (Feeding Sensor/Auto Ejecting)
FC-161ANC-FU
- Features
- When the quantity position in the feeding structure is lower than optical fiber sensor, the pad printing machine will stop working
Description
Progressive Propulsion fixture with cylinder operate. pad printing machine use Piece by piece free fall feeding system. Dryer Equipped, Enhance evaporating and drying the ink. Auto Stop Setting Function : When the quantity position in the feeding structure is lower than optical fiber sensor, the machine will stop working.
Custom pad printing machines (Feeding Sensor/Auto Ejecting)-FC-161ANC-FU
Fine Cause's pad printing machine imported to industrial I.O.T., combine smart factory App, assist you to implement production management goals through synchronous monitoring.
■ Feature :
-
Progressive Propulsion fixture with cylinder operate
-
pad printing machine use Piece by piece free fall feeding system
-
Dryer Equipped, Enhance evaporating and drying the ink
-
PANASONIC Programmable Logic Controller, 65536 Color TFT Touch Panel
-
pad printing machine use manual feeding structure
-
Malfunction screen display
-
Auto Stop Setting Function : When the quantity position in the feeding structure is lower than optical fiber sensor, the machine will stop working
-
Exclusive Patented "Adjustable Ink-Scraping Device" (Patent No. M311585). Adjust Scraping Pressure Easily
Specifications
| Model | FC-161ANC-FU |
|---|---|
| Color | 1 |
| Cycles/hr | 900~1200 Pcs |
| Machine Size (cm) | L:94 W:83 H:130 |
| Weight | 120 Kgs |
| Pressure(kg/cm2 psi) | 4~6 |
| Power (A)Ampere | 10 |
| Voltage (V) | 220V |
| Max. Printing Area(mm) | 55 |
| Max. Height of Printed Object(mm) | 180mm |
| Height -Pad Stand to Steel Plate(mm) | 100 |
| Max. Steel Plate Size(mm) | L:200 W:90 H:10 |
